Orbea Gain M30i 2024 Gravel eBike

Orbea Gain M30i Gravel e-Bike: No excuses

Orbea Gain M30i, designed for road, capable on gravel. It's never been easier to pick up the bike and get out of the house. Gain's huge range means you can forget about things like battery limitations, and the command center on the top tube puts all the information you need at your fingertips.

Gain provides enough power to dampen the force of gravity, but without taking over or taking away from the satisfaction. Its natural support remains in the background, giving you the feeling of being in better shape than ever before.

Orbea Gain M30i Specifications

FRAMESET

Frame: Orbea Gain Carbon OMR monocoque structure, Integrated Seat clamp with STVZO light, ICR cable routing, Thru Axle 12x142mm rear, thread M12x2 P1, Flat Mount disc, 700x35 max tyre, BB386 EVO, Mahle X20 AMC plug.

Fork: Gain OMR carbon fork, 700x35 maximun tyre, Flat Mount disc, Thru Axle 12x100mm, thread M12x2 P1.

Headset: FSA 1-1/2" Integrated Aluminium Cup.

ELECTRIC SYSTEM

Drive Unit: Mahle motor hub X20, ALC.

Battery: Mahle iX350 36V 353Wh.

Charger: Mahle Active Charger up to 4A.

Display: Mahle Pulsar One monochrome ANT+ LEV.

UI/Remote: Mahle ONE Head Unit (BT/ANT+).

DRIVETRAIN

Derailleur: Shimano 105 R7100.

Shifters: Shimano R7120.

Chain: Shimano M7100.

Crankset: Shimano 105 R7100 34x50t.

Cassette: Shimano 105 R7100 11-34t 12-Speed.

BRAKES

Brakes: Shimano R7170 Hydraulic Disc.

WHEELS

Rims: Alloy, Tubeless, 700c, 21c.

Hubs: (F) Orbea Thru Axle 12x100mm M12x2 P1 Lite | (R) Orbea Thru Axle 12x142mm M12x2 P1 Lite.

Tires: Pirelli P ZERO™ Race SmartEVO TLR 700x30c.

COMPONENTS

Handlebar: OC Road Performance RP21 Alu SL, Reach 80, Drop 125.

Stem: OC Road Performance RP10, -8º.

Saddle: Fizik Aliante R5.

Seat Post: SP 0.2 Carbon, 27.2mm, Setback 20.

* We reserve the right to modify the information and components of the products appearing on this website without prior notice, including equipment, specifications, models, colors and materials.
